0.020″ To 3″ Thickness Magnesium Alloy Sheet For Shearing / Stamping / Punching / Drilling

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: High Broad or OEM
Chứng nhận: ISO
Model Number: AZ31B,AZ91D,ZK60,WE43
Thanh toán:
Minimum Order Quantity: 10 kgs
Giá bán: negotiable
Packaging Details: In carton, on pallet
Delivery Time: 100 kgs: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 100mt/month

Thông tin chi tiết

Tên sản phẩm: Tấm hợp kim magiê để khắc CNC, dập nổi, khắc, dập Tên khác: Tấm hợp kim magiê
Vật chất: Hợp kim magiê magiê nguyên chất ứng dụng: CNC khắc, dập nổi, khắc, dập
Kiểu: Cuộn nóng, ép đùn, đúc bề mặt: Không có lớp phủ
Công nghiệp: Máy tính, In ấn, Camera, Điện thoại di động

Mô tả sản phẩm

AZ31B-O Sheet & Plate From 0.020″ to 3″ thickness magnesium alloy plate



Used for:



shearing, stamping, punching, drilling, bending, flame cutting, expanding, swedging, perforating, welding, saw cutting, roll forming, grinding, coating, assembly, packaging, labeling, blanchard grinding, sonic testing & trepanning





Specifications:



Commodity :   Magnesium alloy plate / Magnesium alloy Sheet

Type          :     AZ31B  , AZ91

Sheet Size  Range:

Thickness :    0.3mm , 0.5 mm, 0.7mm, 1.0mm, 1.5mm , 1.75mm , 2mm
                     2mm, 3mm, 4mm , 5mm, 6mm, 7mm, 10mm,
                     and more

Width x Length:  can be anysize.

Regular size:      610 x 914mm

Production method:

Cast & Roll
Hot rolling
Extruding

Test report:



MECHANICAL PROPERTIES

Alloy and Temper Thickness (mm)

Yield Strength

0.2% offset (MPa)

Tensile strength

(MPa)

Elongation

In 5.65 √A (%)

AZ31B O 0.5 – 1.5 125 221 10
1.5 – 6.3 105 221 9
6.3 - 75 105 221 8
AZ31B H24 0.5 – 6.3 200 269 5
6.3 -9.5 179 262 7
9.5 – 12.7 165 255 8
12.7 - 25 152 248 8
25- 50 138 234 6
50 - 80 124 234 7
AZ31B H26 6.3 - 10 186 269 6
10 – 12.5 179 262 6
12.5 - 20 172 255 5
20 – 25 159 255 5
25 - 40 152 241 5
40 - 50 148 241

5





Chemical :



Al: 2.5-3.5%; Zn: 0.7-1.3%; Mn: 0.20 – 1.0%; Mg: Balance

PHYSICAL PROPERTIES:

Density: 1.78

Coefficient of thermal expansion: 26.8 x 10-6K-1

Specific heat: 1040 Jkg-1k-1

Thermal conductivity: 76.9Wm-1k-1

Electrical resistivity: 92nΩm

Modulus of elasticity: 45 x 109Pa

Poissons ratio: 0.35

Melting range: 566 - 632°C




Applications:



Where is Magnesium used?

  • Aerospace, defense and satellite applications where weight reduction is critical
  • Electronic components where shock absorbing qualities are crucial
  • Automotive/Motor sports applications where weight reduction and strength are required
  • Mechanical vibration shakers for test fixtures



Why Magnesium?

  • Magnesium is the lightest industrial metal in the world
  • One third lighter than aluminum
  • Magnesium is as strong as aluminum
  • Magnesium is shock absorbing and dampens vibrations
  • Magnesium is very machinable
  • We supply AZ31, AZ61, AZ80, and ZK60 Alloys, among others


Magnesium is the third-most-commonly-used structural metal, following iron and aluminum.
The main applications of magnesium are, in order: component of aluminum alloys, in die-casting (alloyed with zinc), to remove sulfur in the production of iron and steel, the production of titanium in the Kroll process.
Magnesium, in its purest form, can be compared with aluminum, and is strong and light, so it is used in several high-volume part manufacturing applications, including automotive and truck components.

Magnesium sheet and plate find application in medium strength service at temperatures below 150C. Diverse uses including aircraft fuselage, concrete tools, cell phone, camera, notebook computer cases and textile machinery.
